Description
Beads:
· Saw beads with diameter 11.5mm, 11.0mm, 10.5mm, 10.0mm, 8.8mm, 7.3mm, 6.3mm
· Usable diamond thickness 1.5mm and 1.15mm
· High impact-resistant synthetical diamond
· Even wear of the diamond beads
· Development of smaller diameter
Specification
| For Granite/Sandstone Quarrying | |||||||
| Item | Diameter | Coating | Beads number | Cutting material | Line speed | Cutting speed | Life |
| WGM115 WGM110 | Φ11.5mm Φ11.0mm | Rubber Rubber +Spring | 40/meter | Hard granite | 18-22 m/s | 2-4 m2/h | 7-9m2/m |
| Middle hard granite | 22-25m/s | 4-8 m2/h | 8-15m2/m | ||||
| Soft granite | 25-30m/s | 8-12m2/h | 16-22m2/m | ||||
| WSM115 WSM110 | Φ11.5mm Φ11.0mm | Rubber Rubber +Spring | 40/meter | Hard Sandstone | 32-36m/s | 5-10m2/h | 10-20m2/m |
| Soft Sandstone | 28-32m/s | 1-5m2/h | 15-30m2/m | ||||
| Other sizes are also available | |||||||
| For Marble Quarring | |||||||
| Item | Diameter | Coating | Beads number | Cutting material | Line speed | Cutting speed | Life |
| WMM115 WMM110 WMM105 | Φ11.5mm Φ11.0mm Φ10.5mm | Rubber | 40/meter 37/meter 33/meter | Hard marble | 20-30 m/s | 4-9 m2/h | 15-25m2/m |
| Middle hard marble | 20-35m/s | 8-15 m2/h | 15-35m2/m | ||||
| Soft marble | 25-35m/s | 10-20m2/h | 20-50m2/m | ||||
| Φ11.0mm Φ10.5mm | Spring+Plastic | 30/meter 28/meter | Hard marble | 20-30m/s | 4-9m2/h | 15-25m2/m | |
| Middle hard marble | 20-35m/s | 8-15 m2/h | 15-35m2/m | ||||
| Soft marble | 25-35m/s | 10-20 m2/h | 20-50m2/m | ||||
| Other sizes are also available | |||||||
| For Profiling | |||||||
| Item | Diameter | Coating | Beads number | Cutting material | Line speed | Cutting speed | Life |
| WGP088 WGP084 | Φ8.8mm Φ8.4mm | Rubber Plastic | 40/meter 37/meter | Hard granite | 25-30 m/s | 7-10 m2/h | 7-10m2/m |
| Middle hard granite | 25-30m/s | 8-15 m2/h | 10-15m2/m | ||||
| Soft granite | 25-30m/s | 10-20m2/h | 15-20m2/m | ||||
| WMP088 WMP084 | Φ8.8mm Φ8.4mm | Plastic | 37/meter 33/meter | Hard marble | 30-40m/s | 10-20m2/h | 20-30m2/m |
| Middle hard marble | 30-40m/s | 15-25 m2/h | 25-35m2/m | ||||
| Soft marble | 30-40m/s | 20-30 m2/h | 30-40m2/m | ||||
| Other sizes are also available | |||||||
| Multi-wire saw for block cutting | |||||||
| Item | Diameter | Coating | Beads number | Cutting material | Line speed | Sawing speed | Life |
| WMW730 | Φ7.3mm | Plastic | 37/meter | hard granite | 26-32 m/s | 10-30cm/h | 6-9m2/m |
| middle hard granite | 26-32 m/s | 30-45cm/h | 9-13m2/m | ||||
| soft granite | 26-32 m/s | 40-55cm/h | 14-17m2/m | ||||
| WMW730-Q | Φ7.3mm | Plastic | 37/meter | Quartz | 26-32 m/s | 10-20cm/h | 4-6m2/m |
| Other sizes are also available | |||||||
